12dBi 806-960MHz Outdoor Directional Panel Antenna Cellular CDMA GSM Single Sector Panel Antenna

Short Description:

12dBi 806-960MHz Outdoor Directional Panel Antenna CDMA GSM Single Sector Panel Antenna   Feature: ●High gain ●Full day working ●Optimized dimension ●Vertical polarization   Application: ●CDMA,GSM system ● Wireless communication and data transmission system KTMXP-8090V-D12L65   Electrical Specifications Frequency range(MHz) 806~960 Polarization Vertical Gain(dBi) 12 Half-power beam width(°) H:65   V:14 Front-to-back ratio(dB) ≥25 Input Impeda...


  • Brand: Kingtone/JIMTOM
  • Min.Order Quantity: 1 Piece/Pieces
  • Supply Ability: 10000 Piece/Pieces per Month
  • Warranty: 12months
  • Item: Outdoor Panel Antenna
  • High Gain: 12dBi
  • Frequency : 806-960MHz
  • Product Detail

    Product Tags

    12dBi 806-960MHz Outdoor Directional Panel Antenna CDMA GSM Single Sector Panel Antenna



    Feature:
    ●High gain
    ●Full day working
    ●Optimized dimension
    ●Vertical polarization



    12dBi-Panel-Antenna.1

    12dBi-Panel-Antenna.2
    Application:
    ●CDMA,GSM system
    ● Wireless communication and data transmission system

    KTMXP-8090V-D12L65

      Electrical Specifications

    Frequency rangeMHz

    806960

    Polarization

    Vertical

    GaindBi

    12

    Half-power beam width°

    H:65   V:14

    Front-to-back ratiodB

    ≥25

    Input ImpedanceΩ

    50

    VSWR

    ≤1.5

    Sidelobe suppression for first sidelobe above horizon

    12 dB

    Maximum input powerW

    400

    Lightning protection DC Ground

    Mechanical Specifications

    Input connector type

    N Female

    Dimensions-mm (Height/Width/Depth)

    1300*280*80

    Packing sizemm

    1350*320*160

    Antenna weight kg

    8.3

    Radome material

    UPVC

    Radome color

    Gray

    Mechanical tilt°

    010

    Operating temperature°c

    -4060

    Rated Wind Velocitym/s

    60

    Mounting hardwaremm

    3590
