Kingtone Mobile Signal Booster is a top of the line product that supports frequency bands (Band4:AWS1700/2100MHz &Band5:850MHz). The adjustable controls all you to change your signal preferences for smoother voice and data transmissions. Experience improved signal strength regardless of your phone’s present coverage strength or frequency band!
Main Features:
◇ High linearity PA; High system gain；
◇ Intelligent ALC technology；
◇ Full duplex and high isolation from uplink to downlink；
◇ Automatic Operation convenient operation；
◇ Integrated technique with reliable performance;
◇ Local and remote monitoring (optional) with automatic fault alarm &remote control;
◇ Weatherproof design for all-weather installation;
| Items | Testing Condition | Specification | MEMO | ||||
| Uplink | Downlink | ||||||
|
Working Frequency(MHz) |
B5 |
Nominal Frequency |
824-849MHz |
869-894MHz |
|||
|
B4 |
Nominal Frequency |
1710-1755MHz |
2110-2155MHz |
||||
|
Bandwidth |
B5 |
Nominal Band |
25MHz |
||||
|
B4 |
Nominal Band |
45MHz |
|||||
|
Gain(dB) |
Nominal Output Power-5dB |
95±3 |
|||||
|
Output Power (dBm) |
B5 |
LTE modulating signal |
+37 |
+43 |
|||
|
B4 |
LTE modulating signal |
+37 |
+43 |
||||
|
ALC (dBm) |
Input Signal add 20dB |
△Po≤±1 |
|||||
|
Noise Figure (dB) |
Working in-band（Max. Gain） |
≤5 |
|||||
|
Ripple in-band (dB) |
Nominal Output Power -5dB |
≤3 |
|||||
|
Frequency Tolerance (ppm) |
Nominal Output Power |
≤0.05 |
|||||
|
Time Delay (us) |
Working in-band |
≤5 |
|||||
|
ACLR |
Working in-band |
Compatible with 3GPP TS 36.143 and 3GPP TS 36.106 |
For LTE, PAR=8 |
||||
|
Spectrum Mask |
Working in-band |
Compatible with 3GPP TS 36.143 and 3GPP TS 36.106 |
For LTE, PAR=8 |
||||
|
Gain Adjustment Step (dB) |
Nominal Output Power -5dB |
1dB |
|||||
|
Gain Adjustment Range(dB) |
Nominal Output Power -5dB |
≥30 |
|||||
|
Gain Adjustable Linear(dB) |
10dB |
Nominal Output Power -5dB |
±1.0 |
||||
|
20dB |
Nominal Output Power -5dB |
±1.0 |
|||||
|
30dB |
Nominal Output Power -5dB |
±1.5 |
|||||
|
Spurious Emission(dBm) |
9kHz-1GHz |
BW:30KHz |
≤-36 |
≤-36 |
|||
|
1GHz-12.75GHz |
BW:30KHz |
≤-30 |
≤-30 |
||||
|
VSWR |
BS/MS Port |
1.5 |
|||||
|
I/O Port |
N-Female |
||||||
|
Impedance |
50ohm |
||||||
|
Operating Temperature |
-25°C ~+55°C |
||||||
|
Relative Humidity |
Max. 95% |
||||||
|
MTBF |
Min. 100000 hours |
||||||
|
Power Supply |
DC-24V/DC-48V/AC220V(50Hz)/AC110V(60Hz)( ±15%) |
||||||
|
Remote Monitoring Function (Option) |
Real-time alarm for Door Status, Temperature, Power Supply, VSWR, Output Power |
||||||
|
Remote Control Module (Option) |
RS232 or RJ45 + Wireless Modem + Chargeable Li-ion Battery |
||||||
